The Vertiv Liebert® GXT RT+ UPS is an online double conversion solution which offers power protection in an affordable, efficient system with deployment and operation flexibility.

The high 0.9 power factor of the single-phase Liebert GXT RT+ enables continuous, reliable power to more connected devices from a wide range of input voltages while being energy efficient and, delivering maximum value. The ECO mode of operation for this already affordable UPS also drives energy cost savings for a compelling total cost of ownership (TCO).

Being able to mount the Liebert GXT RT+ in a rack or tower is a convenience that adds to the value story as does the capability of the UPS to utilize external battery cabinets for scalable runtimes.

In addition to the extended runtime, having multiple monitoring options makes this compact UPS ideal for delivering best-in-class power protection to equipment deployed at the edge of networks or in space-constrained facilities.

Technical Specifications

GXTRT-1000IRT2UXL GXTRT-1500IRT2UXL GXTRT-2000IRT2UXL GXTRT-3000IRT2UXL
Ratings (VA/W) 1000/900 1500/1350 2000/1800 3000/2700
Dimensions,mm,Unit (W x D x H) 438 x 310 x 86 438 x 310 x 86 438 x 310 x 86 438 x 632 x 240
Dimensions,mm,Shipping (W x D x H) 600 x 500 x 240 700 x 565 x 240 700 x 565 x 240 600 x 760 x 240
Weight, kg
Unit 11 15.9 18.2 26.6
Shipping 16.3 22.3 24.7 34.1
Input AC Parameters*
Input voltage range (VAC) 120-300 120-300 120-300 120-300
Frequency Range (Hz) 40-70 40-70 40-70 40-70
Input Power connector IEC60320 C14 IEC60320 C14 IEC60320 C14 EC60320 C20
Output AC Parameters
Output Receptacles 6 x IEC60320 C13 6 x IEC60320 C13 6 x IEC60320 C13 6 x IEC60320 C13
1 x IEC60320 C19
Output Voltage (VAC) 220/230/240 220/230/240 220/230/240 220/230/240
Waveform Pure Sine wave Pure Sine wave Pure Sine wave Pure Sine wave
Output (AC Mode) Overload <130% for 30 seconds
<150% for 3 seconds
<130% for 30 seconds
<150% for 3 seconds
<130% for 30 seconds
<150% for 3 seconds
<130% for 30 seconds
<150% for 3 seconds
Environmental
Operating Temperature, °C (°F) 0 to 40 (32 to 104) 0 to 40 (32 to 104) 0 to 40 (32 to 104) 0 to 40 (32 to 104)
Storage Temperature, °C (°F) -20 to 50 (-4 to 122) -20 to 50 (-4 to 122) -20 to 50 (-4 to 122) -20 to 50 (-4 to 122)
Relative Humidity
(%, non-condensing)
<2,000 <2,000 <2,000 <2,000
Audible Noise (line mode) 55 dBA max @ 1m 55 dBA max @ 1m 55 dBA max @ 1m 55 dBA max @ 1m

Available models

The Vertiv™ Liebert® GXT RT+ UPS is an online double conversion solution which offers power protection in an affordable, efficient system with deployment and operation flexibility. The high 0.9 power factor of the single-phase Liebert GXT RT+ enables continuous, reliable power to more connected devices from a wide range of input voltages while being energy efficient and, delivering maximum value. The ECO mode of operation for this already affordable UPS also drives energy cost savings for a compelling total cost of ownership (TCO). Being able to mount the Liebert GXT RT+ in a rack or tower is a convenience that adds to the value story as does the capability of the UPS to utilize external battery cabinets for scalable runtimes. In addition to the extended runtime, having multiple monitoring options makes this compact UPS ideal for delivering best-in-class power protection to equipment deployed at the edge of networks or in space-constrained facilities

The Vertiv™ Liebert ®GXT RT+ UPS is an online double conversion solution which offers power protection in an affordable, efficient system with deployment and operation flexibility. The high 0.9 power factor of the single-phase Liebert GXT RT+ enables continuous, reliable power to more connected devices from a wide range of input voltages while being energy efficient and, delivering maximum value. The ECO mode of operation for this already affordable UPS also drives energy cost savings for a compelling total cost of ownership (TCO). Being able to mount the Liebert GXT RT+ in a rack or tower is a convenience that adds to the value story as does the capability of the UPS to utilize external battery cabinets for scalable runtimes. In addition to the extended runtime, having multiple monitoring options makes this compact UPS ideal for delivering best-in-class power protection to equipment deployed at the edge of networks or in space-constrained facilities

The Vertiv™ Liebert ® GXT RT+ UPS is an online double conversion solution which offers power protection in an affordable, efficient system with deployment and operation flexibility. The high 0.9 power factor of the single-phase Liebert GXT RT+ enables continuous, reliable power to more connected devices from a wide range of input voltages while being energy efficient and, delivering maximum value. The ECO mode of operation for this already affordable UPS also drives energy cost savings for a compelling total cost of ownership (TCO). Being able to mount the Liebert GXT RT+ in a rack or tower is a convenience that adds to the value story as does the capability of the UPS to utilize external battery cabinets for scalable runtimes. In addition to the extended runtime, having multiple monitoring options makes this compact UPS ideal for delivering best-in-class power protection to equipment deployed at the edge of networks or in space-constrained facilities

The Vertiv™ Liebert ® GXT RT+ UPS is an online double conversion solution which offers power protection in an affordable, efficient system with deployment and operation flexibility. The high 0.9 power factor of the single-phase Liebert GXT RT+ enables continuous, reliable power to more connected devices from a wide range of input voltages while being energy efficient and, delivering maximum value. The ECO mode of operation for this already affordable UPS also drives energy cost savings for a compelling total cost of ownership (TCO). Being able to mount the Liebert GXT RT+ in a rack or tower is a convenience that adds to the value story as does the capability of the UPS to utilize external battery cabinets for scalable runtimes. In addition to the extended runtime, having multiple monitoring options makes this compact UPS ideal for delivering best-in-class power protection to equipment deployed at the edge of networks or in space-constrained facilities

Key Features

  • Online technology with two stages of power conversion
  • Output power factor higher than majority of comparable competitor models
  • Flexible rack/tower form factor
  • External battery cabinet compatibility
  • User-friendly liquid crystal display (LCD)
  • High efficiency ECO mode - User replaceable hot-swappable batteries
  • Wide input voltage operation (120-300V AC)
  • RoHS and REACH compliance
